Bullet Female Terminal
Product Details:
X
Product Description
Bullet Female Terminal
We remain accessible in meeting the high-end demands of our clients. Our products are the result of highly advanced designing methodology and state of art technology. The Bullet Female Terminal are highly useful articles that are known for their durability and longer functional life. Our huge manufacturing unit is equipped with highly sophisticated machines that offer higher production without affecting the quality. The Bullet Male & Female Terminal are available in below given sizes and specifications.
| PART NO | ITEM NAME | T | L | W | OD | ID | C1 | C2 |
| ME-036 | CW-104 | 0.40 | 20.70 | 11.00 | 4.50 | - | 4.10 | 3.50 |
| ME-045 | S/NALKI | 0.40 | 24.50 | - | 5.00 | 4.00 | 7.75 | 6.50 |
| ME-047 | CB-104 | 0.35 | 17.50 | - | 4.60 | 3.80 | 3.60 | 3.40 |
| ME-077 | Bullet Tube | 0.40 | 23.25 | - | 5.40 | 4.30 | - | - |
| ME-087 | FW-104(Bullet) | 0.40 | 22.25 | 11.40 | - | 4.10 | - | - |
| PART NO | ITEM NAME | T | L | OD | C1 | C2 |
| ME-046 | CA-104D/B | 0.40 | 17.80 | 3.96 | 4.00 | 3.50 |
| ME-049 | HI-TUBE | 0.40 | - | - | - | - |
| ME-075 | CA-103 | 0.40 | 16.00 | 3.50 | 3.80 | 3.60 |
